£124.99£137.99

Cable Type:

Cable Length:

Rated Power (Charge Speed):

Accessory Add-Ons

Free Next Working Day Delivery

  • Type Type 2 to Type 2 Charging Cable
  • Length 10M
  • Rated Power 16amp (3.6kW)
  • Warranty 2 Years
  • Accessories No Add-Ons

Check compatibility

Use our car reg compatibility checker to make sure your getting the right charger for you vehicle.

Product Description

DS dropped Crossback from the name at the 2023 facelift, but the socket stayed Type 2 and the real change was underneath. The 2020 to 2022 car, 46.3 kWh usable, had a 7.4 kW charger with 11 kW as an option, and the 2023 DS 3 E-Tense, 50.8 kWh usable, has 11 kW as standard. On a single phase UK home supply both charge at 7.4 kW, so the early car fills in about 7 hours and the facelift in 7 hours 45 minutes.

Pick your DS 3 Crossback charging cable

  • 32A single phase: an easy overnight charge on either generation.
  • 32A three phase: for a facelift, or an early car with the optional charger, used regularly at a three phase post, where it takes 11 kW and the facelift fills in 5 hours 15 minutes.
  • 16A: past 14 hours on the early car, so only where your supply is capped at 16A.
  • Type 2 to 3 Pin: 22 hours 45 minutes to 25 hours from empty, an emergency lead rather than a routine.

Many public AC posts have no lead of their own, so the Type 2 to Type 2 earns a place in the boot as well as on the drive. Choose 5m for a wallbox beside the bay and 10m for reach; beyond that, the 15m and 20m 32A cables suit a car kept on the street or a charger past another parked car. For a 13 amp socket there is the Type 2 to 3 Pin, which protects itself with an integral RCD and lets you pick a lower current.

Why buy your DS 3 Crossback cable from EV Cable Shop

  • Over 600 Trustpilot reviews and an Excellent rating. Read the reviews.
  • Free UK delivery, next working day. Orders in by 2pm leave us the same day.
  • Free exchanges for 30 days. Measured wrong? Return it and we send the length you need.
  • 2 years of manufacturer's warranty cover on CE marked cables built to IEC standards.
  • Matched to your car, not upsold. Neither DS 3 can take more than 7.4 kW at home, so we recommend 32A single phase and only suggest three phase to owners who charge at a three phase post.
  • A UK family business.

See every lead for the brand in DS charging cables, or the larger SUV on the DS 7 Crossback charging cable page.

DS 3 Crossback Charging Times

DS 3 Crossback E-Tense 50 kWh, 136hp, 2020 to 2022, 46.3 kWh usable

Cable TypeMax Charge RateEmpty to FullVerdict
Type 2 to 3 Pin (5m / 10m)2.3 kW22h 45mEmergency use only
Type 2 to Type 2, 16A (5m / 10m)3.7 kW14h 15mOnly if your supply is capped at 16A
Type 2 to Type 2, 32A (5m / 10m)7.4 kW7h 00mBest choice at home
Type 2 to Type 2, 32A three phase (5m / 10m)11 kW with the optional charger4h 45mOnly on a three phase post

DS 3 E-Tense 54 kWh, 156hp, 2023 onwards, 50.8 kWh usable

Cable TypeMax Charge RateEmpty to FullVerdict
Type 2 to 3 Pin (5m / 10m)2.3 kW25h 00mEmergency use only
Type 2 to Type 2, 16A (5m / 10m)3.7 kW15h 30mOnly if your supply is capped at 16A
Type 2 to Type 2, 32A (5m / 10m)7.4 kW7h 45mBest choice at home
Type 2 to Type 2, 32A three phase (5m / 10m)11 kW as standard5h 15mOnly on a three phase post

Features

Type 2 charging cable connector
Durable

We pride ourselves on the quality of our cables. Every cable comes with a 2 year manufacturer's warranty, and the jacket will survive being driven over, though we would rather you did not make a habit of it.

Run-over Proof

Protection against pressure

All Weather

Our cables are safe to use whatever the weather. Type 2 to Type 2 cables are IP55 rated, CE marked, and work from -30°C to +50°C. Type 2 to 3 pin cables are IP67 rated, CE marked and work from -30°C to +60°C.

All weather rated

Protection against temperature

Versatile

Our cables fit any electric car or plug-in hybrid with a Type 2 inlet, including Audi, BMW, Volvo, Mini, Mercedes, Kia, Hyundai, Volkswagen, Smart and Toyota. Use our car reg checker to confirm your car.

Universal Charger

Compatible with all Type 2 cars

Information

Technical Spec Sheet
Download
Warranty
Download
User Manual
Download

Videos

Impact Resistance

Our EV Charging Cables are designed for high durability, capable of withstanding drops from a height of 2 metres. The video above demonstrates the impressive impact resistance of our cables.

Waterproof Design

Our EV Charging Cables are built to perform in all weather conditions. As showcased in the video above, these cables are fully waterproof, ensuring reliable charging even in wet environments.

FAQs

DS 3 Crossback Charging Cable FAQs

Which cable suits the DS 3 Crossback E-Tense?

A Type 2 to Type 2 cable in 32A. Every electric DS 3 has a Type 2 socket, and 32A carries 7.4 kW, the maximum a UK home supply can deliver. That fills the 46.3 kWh early car in about seven hours and the 50.8 kWh facelift in about seven and three quarter hours.

Is the three phase cable worth it on a DS 3?

Only if you charge on three phase power away from home. The facelift takes 11 kW as standard and the earlier car needed the optional charger to do the same, cutting a full charge to roughly 5 hours 15 minutes or 4 hours 45 minutes. On a home supply both cars sit at 7.4 kW.

How long does a DS 3 E-Tense take to charge?

On a 7.4 kW wallbox, about 7 hours for the 46.3 kWh usable car built to 2022 and about 7 hours 45 minutes for the 50.8 kWh version from 2023. A 16A cable pushes those to roughly 14 hours 15 minutes and 15 hours 30 minutes, so it is a poor swap.

Is the DS 3 E-Tense the same as the Crossback?

Yes, the badge simply lost a word. Cars from 2020 to 2022 are DS 3 Crossback E-Tense with a 50 kWh pack, and the 2023 facelift became DS 3 E-Tense with 54 kWh and 156hp. The Type 2 socket is unchanged across both, so one cable fits whichever you own.

Does the petrol DS 3 need a charging cable?

No. The PureTech petrol and BlueHDi diesel DS 3 and DS 3 Crossback have no charging port and no traction battery, so nothing here will connect to them. There has never been a plug-in hybrid DS 3 either. Only the E-Tense badge takes a cable.

Should I choose 5m or 10m for a DS 3?

Five metres is fine when the wallbox is fitted within reach of your usual parking spot. Ten metres covers awkward driveways, a garage wall on the far side, or public posts where you take whichever bay is free. Longer 15 metre and 20 metre 32A cables are listed too.

Specification

Technical Specification

Showing both cable types. Choose a cable type above and this section will show just that specification.

Which cable should you choose
Type 2 to Type 2 Type 2 to 3 pin
Charges fromA home wallbox or a public charge pointAny standard UK 3 pin socket, no wallbox needed
Max power3.7 kW at 16A, 7.4 kW at 32A, 22 kW on three phase2.3 kW
Speed at home7.4 kW on a 32A cable. UK homes are single phase, so an 11 kW or 22 kW car still draws 7.4 kW2.3 kW
Range per hourAbout 12 miles at 3.7 kW, 25 miles at 7.4 kWAbout 8 miles
Weatherproof ratingIP55IP67
Temperature-30°C to +50°C-30°C to +60°C
Built toIEC 62196-2:2016 2-IIbIEC 62752:2016 / COR1:2019
CertifiedCECE
Best forYour everyday charging cableBackup, and away from home where there is no wallbox
Choose this Select Type 2 to Type 2 for the DS 3 Crossback Select Type 2 to 3 pin for the DS 3 Crossback
Full range All Type 2 to Type 2 cables All Type 2 to 3 pin cables
Type 2 to Type 2, full specification
Charging performance
Connector typeType 2 to Type 2 (IEC 62196-2:2016 2-IIb, Mennekes)
Rated current16A or 32A single phase, or 32A three phase
Max power3.7 kW at 16A, 7.4 kW at 32A, 22 kW on three phase
Speed at home7.4 kW. UK homes are single phase, so an 11 kW or 22 kW car still draws 7.4 kW
Range per hourAbout 12 miles at 3.7 kW, 25 miles at 7.4 kW
Slower suppliesFine. Charging runs at the lowest limit of the car, the charge point and the cable, so a 32A cable works normally on a 16A supply
VoltageAC 250V single phase, AC 400V three phase, 50Hz
Signal current2A at 30V
Full rangeAll Type 2 to Type 2 cables
Cable and construction
Lengths5m, 10m, 15m, 20m
Conductors16A: 3 x 2.5mm² plus 2 x 0.5mm²
32A single phase: 3 x 6mm² plus 2 x 0.5mm²
32A three phase: 5 x 6mm² plus 1 x 0.5mm²
InsulationXLPO
SheathTPU
ShellFlame retardant thermoplastic, UL94-V0
PinsCopper alloy, silver plated
ColourBlack cable, green and black connectors
Durability and compliance
Weatherproof ratingIP55 in use
Temperature-30°C to +50°C
Mechanical lifeOver 1,000 connections
ImpactSurvives a 1m drop and a 2 tonne vehicle driving over it
Plug forceUnder 100N
Insulation resistanceOver 1,000 MΩ at DC 500V
Withstand voltage2,500V
Contact impedance0.5 mΩ maximum
Pin temp riseUnder 50K
Built toIEC 62196-2:2016 2-IIb
CertifiedCE
Type 2 to 3 pin, full specification
Charging performance
Connector typeType 2 to 3 pin, BS1363 13A plug
Socket neededAny standard UK 3 pin socket. No wallbox needed
Max power2.3 kW
Current6A to 10A, set on the control box
Voltage230V AC, 50Hz
Range per hourAbout 8 miles
OvernightAbout 100 miles in 12 hours
Full rangeAll Type 2 to 3 pin cables
Safety and protection
Weatherproof ratingIP67
RCDBuilt in, Type B
ProtectionOver and under voltage, overload, short circuit, earth leakage, over temperature and lightning surge
Built toIEC 62752:2016 / COR1:2019
CertifiedCE
Control box
DisplayOLED screen: charging time, energy used, live voltage, current and power, and lifetime total
ControlsTouch key, LED status light, adjustable current, delay timer
Box size200 x 90 x 52 mm
WeightUp to 2.1 kg
CoolingNatural air
Standby powerUnder 0.5 W
ConnectivityNone. No WiFi, Bluetooth, 4G or Ethernet
Build and materials
Lengths5m, 10m, 15m
Temperature-30°C to +60°C
HumidityUp to 95%
Max altitude2,000m
MaterialsTempered glass and PC control box
ColourBlack
Warranty and delivery
In the boxCharging cable only. The premium storage carry bag is sold separately
Warranty2 year warranty
DeliveryFree next working day UK delivery

Compatibility

The electric DS 3 is Type 2 on every version, so any Type 2 to Type 2 cable fits. Two things are worth checking. First, the name changed: DS dropped Crossback from the badge for the 2023 facelift, so the same car is a DS 3 Crossback E-Tense before then and simply a DS 3 E-Tense afterwards. Second, the charger changed with it. The original 50 kWh car had 7.4 kW as standard with 11 kW as an option; the 54 kWh facelift has 11 kW as standard. That only matters on three-phase power, though. On a UK home supply both charge at 7.4 kW. The petrol and diesel DS 3 have no charging port, and there has never been a plug-in hybrid DS 3.

BadgeYearsBatteryConnectorMax AC charge speedCable we recommend
DS 3 Crossback E-Tense 50 kWh, 136hp2020 to 202146.3 kWh usable, 50 grossType 2, plus CCS rapid at 101 kW7.4 kW standard, 11 kW optionalType 2 to Type 2, 32A
DS 3 Crossback E-Tense 50 kWh, later carsLate 2021 to 202246.3 kWh usableType 2, plus CCS rapid7.4 kW standard, 11 kW optionalType 2 to Type 2, 32A
DS 3 E-Tense 54 kWh, 156hp, Crossback name dropped2023 onwards50.8 kWh usable, 54 grossType 2, plus CCS rapid at 107 kW11 kW standard, which is 7.4 kW on a UK home supplyType 2 to Type 2, 32A for home. 32A three phase for three-phase posts
DS 3 and DS 3 Crossback PureTech petrol or BlueHDi diesel2019 onwardsNoneNo charging portDoes not plug inNo cable needed

DS 3 Crossback Charging Cable

£124.99£137.99

Cable Type:

Cable Length:

Rated Power (Charge Speed):

Accessory Add-Ons

Free Next Working Day Delivery

  • Type Type 2 to Type 2 Charging Cable
  • Length 10M
  • Rated Power 16amp (3.6kW)
  • Warranty 2 Years
  • Accessories No Add-Ons

Check compatibility

Use our car reg compatibility checker to make sure your getting the right charger for you vehicle.

Cable Type:

How do I Choose?
1/4

Cable Length:

Sizing guide
2/4

Rated Power (Charge Speed):

How do I Choose?
3/4

Accessory Add-Ons

4/4
Sizing guide
  • Type 2 to Type 2 Charging Cable:

    A charging cable that connects electric vehicles (EVs) with a Type 2 connector to charging points is also equipped with a Type 2 socket. It supports faster charging speeds and is commonly used across Europe for EVs with this standard connection.

  • Type 2 to 3 Pin Charging Cable:

    This cable allows electric vehicles with a Type 2 socket to charge from a standard UK 3-pin domestic outlet. It provides a slower charge but is useful for home or emergency charging when dedicated charging stations aren't available.

  • Type 2 Extension Cable:

    A cable used to extend the reach of a Type 2 charging cable. It's helpful when the existing cable is too short to connect an electric vehicle to the charging point, providing more flexibility in parking.

  • Type 2 Tethered Cable:

    A fixed charging cable attached to a charging point, designed for electric vehicles with a Type 2 socket. The tethered design eliminates the need to carry a separate cable, offering convenience for regular charging at home or work.

  • Type 1 to Type 2 Charging Cable:

    A charging cable that connects electric vehicles with a Type 1 socket to charging points equipped with a Type 2 outlet. This allows EVs with the older Type 1 standard to use more modern charging infrastructure.

  • Type 1 to 3 Pin Charging Cable:

    This cable enables electric vehicles with a Type 1 connector to charge from a standard UK 3-pin household outlet. It's suitable for slower charging at home when dedicated EV charging points aren't accessible.

Sizing guide
  • 5m - Charging Cable Length

    A 5M charging cable is the shortest length that we offer. It is a great option if you can park close to the charge point and do not need much length to reach your car.

  • 10m - Charging Cable Length

    A 10M charging cable is the most popular length. It allows you to have enough flexibility whilst still being easy enough to move. This is a great option if you cannot park close to the electricity supply.

  • 15m - Charging Cable Length

    A 15M charging cable is a great choice if you need some extra flexibility, i.e. get past another car or reach the other end of a driveway. The length of the cable does not affect the charging speed.

  • 20m - Charging Cable Length

    A 20M charging cable is the longest cable that we currently offer. 20M reaches the vast majority of locations where you would want to charge your car. Always use one continuous cable. Never join two charging cables together and never charge through an extension lead, because the join is where heat builds up.

How to choose your charge speed
  • 6amp – 10amp Adjustable

    The choice if you will charge from a standard UK 3 pin socket. It runs at the most the socket can safely supply, and the control box lets you turn the current down for a slower, gentler charge overnight or on an older circuit.

  • 16amp

    A 16amp cable will be able to charge at 3.7kW. This is the cheapest product if your car's max charge speed is 3.7kW. If you have two electric cars or are looking to purchase another it might be worth considering a faster charging cable as this could limit charge speeds moving forward.

  • 32amp

    A 32amp charging cable will be able to charge at 7.4kW, which is the most a single phase UK home supply can deliver. A 32amp cable also charges at every lower speed (for example 16amp, 3.7kW), so it is the right choice if your home charge point is 7.4kW or you mostly charge at home.

  • 32amp (3 Phase)

    A 32amp 3-phase charging cable will be able to charge at all speeds up to 22kW, so the cable never limits your charge speed at home or in public. It is also capable of charging at all lower charge speeds.
